Frac Flowback Water at Drilling Site

Canada

EPT technology was successful in treating the H2S laden produced water to well below criteria for all required parameters.

Situation

The Oil and Gas industry often produce waste waters laden with toxic H2S.  This deadly component is expensive, time consuming and dangerous to treat using current technologies.  By removing the toxic component and treating the water, it is then available for reuse in further operations such as hydraulic fracturing processes. The goal of using EPT was to determine the effectiveness of the technology for treating this produced water to standards required for reuse.

The Solution



The EPT technology successfully treated H2S laden produced water, while greatly reducing TSS and bacteria, reducing the potential for plugging and fouling.  The mobile EPT unit allows for plug and play mobility while continuing the high quality treatment process.






The Results

The required parameters in treating the H2S laden produced water included H2S, TSS, metals and bacteria. The EPT treated water exceed these parameters now allowing the clean water to be available for reuse and eliminating the need for disposal.





Parameter Unit Initial Post EPT % Removal
Total Suspended Solids mg/L 328.4 0.02 99.9
Hydrogen Sulfide (H2S) mg/L 5.9 0.002 99.9
Sulfide mg/L 5.6 0.002 99.9
Oil and Grease mg/L 83 2 97.6
Bacteria MPN/100ml 2420 < 1 99.9
