Ground Effects successfully treated mining waste water using EOX treatment for high levels of cyanide, nitrate and nitrites.

The Situation

As the environmental regulations continue to become more stringent, and fresh water resources are being greatly reduced or are no longer an option for mining operations, the Mining Industry is turning to technologies to treat existing waste streams, but also make those treated waters available for reuse within the mining operations.

A fully integrated gold exploration and mining company has large existing waste ponds with specific desire to remove naturally occurring cyanide, total suspended solids as well as nitrate/nitrite from the explosive charges used to break rock.


The Solution

GEE's unique electrocatalytic oxidation was successful at treating a wide variety of parameters simultaneously.

This is particularly useful in the mining industry due to the large waste ponds from mining operations that consist of a variety of contaminants.

  • Treated water is now available for reuse in mining operations, reducing or eliminating the need for fresh water
  •
  • On site treatment, with plug and play mobility
  •
  • Eliminates the need for long term storage of waste waters, reducing the risk of leaks and spills.

The Results

  • Treatment of cyanide, TSS, nitrate and nitrite, exceeding criteria for discharge
  • Treated water is now available for reuse in mining operations, reducing or eliminating the need for fresh water
  • Reduction or elimination over time of tailing ponds, allowing vast quantities of treated water now available for operations

ParameterUnitInitialPost EOX% Removal
Nitratemg/L790.01499.98
Nitritemg/L28<0.02099.93
Cyanidemg/L6.4<0.00299.96
TSSmg/L102199.03

Case Study

Sector
Mining
Industrial
Oil & Gas
Agriculture
Location
Northern Saskatchewan, Canada
Key Product
Electrocatalytic Oxidation
Extracted Contaminants
Cyanide
Nitrate
Bacteria
Hydrogen Sulfide
Total Suspended Solids
Heavy metals
